BNC-LR-PC-1(40) - Hirose

BNC-LR-PC-1(40) Details

• Manufacturer Part Number:

  BNC-LR-PC-1(40)

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Hirose Electric Co Ltd

• YTEOL:

  8

• Additional Feature:

  VSWR MAX AT 2GHZ, CONTACT GENDER REFERRED FROM MFR WEBSITE

• Body Breadth:

  0.669 inch

• Body Depth:

  0.97 inch

• Body Length:

  0.472 inch

• Body/Shell Style:

  RECEPTACLE

• Characteristic Impedance:

  50 Ω

• Connector Type:

  RF BNC CONNECTOR

• Contact Finish Mating:

  SILVER

• Contact Gender:

  FEMALE

• Contact Material:

  NOT SPECIFIED

• Contact Resistance:

  3 mΩ

• Contact Style:

  COAX

• Coupling Type:

  BAYONET

• DIN Conformance:

  NO

• Dielectric Withstanding Voltage:

  2100VAC V

• Durability:

  5000 Cycles

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insulation Resistance:

  5000000000 Ω

• Insulator Material:

  TETRAFLUORIDE

• MIL Conformance:

  NO

• Mating Information:

  MULTIPLE MATING PARTS AVAILABLE

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number of Ports:

  1

• Operating Frequency-Max:

  4 GHz

• Option:

  GENERAL PURPOSE

• Panel Mount:

  NO

• Shell Material:

  BRASS

• Terminal Length:

  0.118 inch

• Termination Type:

  SOLDER

• Total Number of Contacts:

  1

• VSWR:

  1.2
