Texas Instruments provides a recommended PCB layout in the datasheet, but it's essential to follow good design practices, such as keeping the power traces short and wide, using a solid ground plane, and placing decoupling capacitors close to the device. Additionally, ensure that the layout is symmetrical to minimize electromagnetic interference (EMI).
The selection of external components, such as resistors, capacitors, and inductors, depends on the specific application and design requirements. Refer to the datasheet for recommended component values and follow the guidelines for component selection. It's also essential to consider factors like component tolerance, temperature rating, and reliability.
The BQ2085DBT-V1P3 has an operating temperature range of -40°C to 85°C. However, it's essential to consider the derating of the device's performance and reliability at higher temperatures. Refer to the datasheet for more information on temperature-related specifications.
To ensure EMC, follow good design practices, such as using a shielded enclosure, keeping the layout compact, and using EMI filters or shielding on the input and output lines. Additionally, consider using a common-mode choke and a ferrite bead to reduce EMI emissions.
The typical start-up time for the BQ2085DBT-V1P3 is around 10-15 ms. However, this time may vary depending on the specific application, input voltage, and output load. Refer to the datasheet for more information on start-up time and related specifications.
