- Datasheet Download Datasheet
- Stock & Prices $ Price & Stock for BQ24003PWPR
- Part Number BQ24003PWPR
- Manufacturer Texas Instruments
- Pin Count 21
- Part Category Integrated Circuit
- Package Category Small Outline Packages
- Footprint Name Small Outline Packages - PWP (R-PDSO-G20) -+-+
- Released Date Apr 5, 2022
- Last Modified Date Nov 29, 2023 6:25 AM UTC
- Pinout / Pin List Click Here (Member Only)
BQ24003PWPR Details
-
Manufacturer Part Number:
BQ24003PWPR
-
Brand Name:
Texas Instruments
-
Pbfree Code:
Yes
-
Rohs Code:
Yes
-
Part Life Cycle Code:
Active
-
Part Package Code:
TSSOP
-
Pin Count:
20
-
Country Of Origin:
Taiwan
-
ECCN Code:
EAR99
-
HTS Code:
8542.39.00.90
-
Manufacturer:
Texas Instruments
BQ24003PWPR Frequently Asked Questions (FAQs)
-
The recommended layout and placement for the BQ24003PWPR can be found in the Texas Instruments application note SLUA364, which provides guidelines for PCB layout, component placement, and thermal management.
-
The BQ24003PWPR has a programmable charging current and voltage limit. You can use the ISET pin to adjust the charging current and the VREG pin to adjust the voltage limit. Refer to the datasheet for the specific equations and calculations to determine the optimal values for your battery.
-
The BQ24003PWPR has an operating ambient temperature range of -40°C to 85°C. However, the device can be derated for higher temperatures. Refer to the datasheet for the thermal derating curve.
-
The BQ24003PWPR has a built-in overcharge protection feature. You can set the overcharge voltage threshold using the VREG pin and the overcharge timer using the TMR pin. Refer to the datasheet for the specific equations and calculations to determine the optimal values for your application.
-
Yes, the BQ24003PWPR is designed to work with lithium-ion batteries. However, you must ensure that the battery's chemistry and characteristics are compatible with the charger's specifications. Refer to the datasheet and the battery's datasheet to ensure compatibility.
Trust Checks
Community Provided
System Verified
Community Approved
BQ24003PWPR Overview
Use the download button to access the BQ24003PWPR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like BQ240,
or try a keyword search, such as Power Management Circuits
