A good PCB layout for the BQ24703PW involves keeping the high-current paths short and wide, using multiple vias to connect the GND pins to the thermal pad, and placing the input capacitors close to the VIN pin. A 4-layer PCB with a solid ground plane is recommended.
To select the right inductor, consider the maximum current rating, inductance value, and DC resistance. A good starting point is to choose an inductor with a saturation current rating above the maximum output current, an inductance value between 1-10uH, and a DC resistance below 100mΩ.
The EN (enable) pin is used to turn the converter on and off. To use it, connect the EN pin to a logic-level signal (e.g., from a microcontroller) to enable or disable the converter. When EN is high, the converter is enabled; when EN is low, the converter is disabled.
The output voltage of the BQ24703PW can be adjusted by changing the resistor divider network connected to the FB (feedback) pin. The output voltage is determined by the ratio of the resistors and the internal reference voltage (0.8V).
The thermal derating curve for the BQ24703PW is provided in the datasheet. As the ambient temperature increases, the maximum output current decreases to prevent overheating. Ensure that the converter is operated within the recommended temperature range to maintain the maximum output current.
