Texas Instruments provides a recommended layout and placement guide in the datasheet, but it's essential to follow good PCB design practices, such as keeping the input and output capacitors close to the IC, using a solid ground plane, and minimizing trace lengths and widths to reduce EMI and noise.
Choose input and output capacitors with low ESR, high ripple current rating, and a voltage rating that exceeds the maximum input voltage. X5R or X7R ceramic capacitors are recommended. The datasheet provides guidance on capacitor selection, but it's crucial to consider the specific application requirements and operating conditions.
The BQ25173QWDRCRQ1 is rated for operation from -40°C to 125°C, but the maximum ambient temperature range depends on the specific application and the device's power dissipation. Ensure that the device is operated within the recommended temperature range to maintain reliability and performance.
The BQ25173QWDRCRQ1 has a built-in OVP feature that can be enabled by connecting the OVP pin to a voltage divider network. This allows the device to detect and respond to overvoltage conditions. Consult the datasheet for specific implementation details and consider adding external protection components, such as a TVS diode, for enhanced protection.
The recommended input voltage range for the BQ25173QWDRCRQ1 is 2.5V to 5.5V, but the device can operate from 2.3V to 5.5V. Ensure that the input voltage is within the recommended range to maintain device performance and reliability.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
BQ25173QWDRCRQ1 Overview
Use the download button to access the BQ25173QWDRCRQ1 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like BQ251,
or try a keyword search, such as Power Management Circuits
