CB3LV-3C-24M0000 - CTS

CB3LV-3C-24M0000 Details

• Manufacturer Part Number:

  CB3LV-3C-24M0000

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  GREEN, CERAMIC PACKAGE-4

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  South Korea, Taiwan

• Factory Lead Time:

  7 Weeks

• Manufacturer:

  CTS Corporation

• YTEOL:

  6.05

• Additional Feature:

  ENABLE/DISABLE FUNCTION; TAPE AND REEL

• Fall Time-Max:

  5 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  50%

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  4

• Operating Frequency-Nom:

  24 MHz

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• Oscillator Type:

  HCMOS/TTL

• Output Load:

  50 pF

• Physical Dimension:

  7.0mm x 5.0mm x 1.7mm

• Rise Time-Max:

  5 ns

• Supply Voltage-Max:

  3.6 V

• Supply Voltage-Min:

  3 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %

• Terminal Finish:

  GOLD OVER NICKEL
