The maximum clock frequency for the CD74HC4024MT is 25 MHz, but it can vary depending on the operating voltage and temperature. It's recommended to check the timing diagrams and switching characteristics in the datasheet to ensure the desired clock frequency meets the device's requirements.
The output enable (OE) pin should be tied low (VSS) to enable the outputs. If OE is tied high (VCC), the outputs will be in a high-impedance state. It's recommended to use a pull-down resistor to ensure the OE pin is properly biased.
A simple POR circuit can be implemented using a resistor, capacitor, and diode. The capacitor should be connected between VCC and VSS, with the resistor in series with the capacitor. The diode should be connected between VCC and the reset pin (MR) to ensure a clean reset signal. The values of the components will depend on the specific application and operating conditions.
To ensure proper signal integrity and reduce noise, it's recommended to use a low-impedance clock source, keep the clock and data lines as short as possible, and use a termination resistor at the receiving end. Additionally, consider using a clock buffer or signal repeater to improve signal quality and reduce jitter.
The maximum input voltage for the CD74HC4024MT is 6.5V, which is the absolute maximum rating. However, the recommended operating voltage range is 2V to 6V. Applying voltages above 6.5V can cause permanent damage to the device.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
CD74HC4024MT Overview
Use the download button to access the CD74HC4024MT schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like CD74H,
or try a keyword search, such as Counters
About Texas Instruments
Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
