The recommended power-up sequence is to apply VCC first, followed by VDD, and then the clock signal. This ensures proper initialization and prevents latch-up.
When using the CDC351DB in a PLL configuration, it's essential to ensure the clock signal is clean and stable. Use a clock buffer or a dedicated clock source to minimize jitter and noise.
The CDC351DB can operate up to 200 MHz, but the actual frequency limit depends on the specific application, PCB layout, and signal integrity. It's recommended to consult the datasheet and perform simulations to determine the maximum frequency for your specific design.
To minimize power consumption, use the lowest possible voltage supply, reduce the clock frequency, and use the power-down mode when not in use. Additionally, consider using a low-power mode or dynamic voltage and frequency scaling (DVFS) if supported by your system.
When designing the PCB layout, ensure proper signal routing, minimize signal length, and use a solid ground plane to reduce noise and electromagnetic interference (EMI). Also, consider using a clock tree architecture to minimize clock skew.
