Texas Instruments provides a recommended layout and routing guide in the CDC906PWR datasheet, but it's essential to follow good PCB design practices, such as keeping the clock signal traces short and away from noisy signals, using a solid ground plane, and minimizing vias and layer changes.
The CDC906PWR is a programmable clock generator, and the configuration depends on the specific clock frequency required. Refer to the datasheet's configuration tables and use the TI Clocking Architect (TCA) software tool to generate the correct register settings for your desired clock frequency.
The CDC906PWR can support input clock frequencies up to 200 MHz, but the maximum frequency depends on the specific device grade and operating conditions. Refer to the datasheet for specific details on the maximum input clock frequency for your device.
Proper power supply and bypassing are crucial for the CDC906PWR's operation. Ensure a stable power supply voltage (1.8V or 3.3V) and follow the recommended bypassing scheme using high-quality capacitors (e.g., 0.1 μF and 10 μF) as close to the device as possible.
The CDC906PWR's power consumption varies depending on the operating frequency, output configuration, and device grade. Typically, the power consumption ranges from 20 mA to 50 mA, but refer to the datasheet for specific details on power consumption for your application.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
CDC906PWR Overview
Use the download button to access the CDC906PWR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like CDC90,
or try a keyword search, such as Clock Generators
