CPH5517 - Sanyo

CPH5517 Details

• Manufacturer Part Number:

  CPH5517

• Part Life Cycle Code:

  Transferred

• Package Description:

  CPH5, 5 PIN

• Pin Count:

  5

• ECCN Code:

  EAR99

• Manufacturer:

  SANYO Semiconductor Co Ltd

• Collector Current-Max (IC):

  1 A

• Collector-Emitter Voltage-Max:

  50 V

• Configuration:

  COMMON BASE, 2 ELEMENTS

• DC Current Gain-Min (hFE):

  200

• JESD-30 Code:

  R-PDSO-G5

• Number of Elements:

  2

• Number of Terminals:

  5

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Polarity/Channel Type:

  NPN AND PNP

• Qualification Status:

  Not Qualified

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON

• Transition Frequency-Nom (fT):

  420 MHz
