CPH5524-TL-E - onsemi

CPH5524-TL-E Details

• Manufacturer Part Number:

  CPH5524-TL-E

• Brand Name:

  onsemi

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  CPH5

• Package Description:

  SC-74A, 5 PIN

• Pin Count:

  5

• Manufacturer Package Code:

  318BC

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• Factory Lead Time:

  16 Weeks

• Manufacturer:

  onsemi

• YTEOL:

  7

• Case Connection:

  EMITTER

• Collector Current-Max (IC):

  3 A

• Collector-Emitter Voltage-Max:

  50 V

• Configuration:

  COMMON EMITTER, 2 ELEMENTS

• DC Current Gain-Min (hFE):

  200

• JESD-30 Code:

  R-PDSO-G5

• JESD-609 Code:

  e6

• Moisture Sensitivity Level:

  1

• Number of Elements:

  2

• Number of Terminals:

  5

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  NPN AND PNP

• Surface Mount:

  YES

• Terminal Finish:

  Tin/Bismuth (Sn/Bi)

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON

• Transition Frequency-Nom (fT):

  380 MHz
