CS8416-CNZ - Cirrus Logic

Description: Audio Transmitters, Receivers, Transceivers 192kHz Digital Audio Receiver

Download CS8416-CNZ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
CS8416-CNZ - Cirrus Logic PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - 28-PIN QFN
click to zoom
3D Models
CS8416-CNZ - Cirrus Logic  - 3D model - Quad Flat No-Lead - 28-PIN QFN
click to zoom

CS8416-CNZ Details

  • Manufacturer Part Number:

    CS8416-CNZ

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    QFN

  • Pin Count:

    28

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    18 Weeks

  • Manufacturer:

    Cirrus Logic

  • YTEOL:

    0

  • Additional Feature:

    ALSO REQUIRES 3.13V TO 5.25V SUPPLY

  • Consumer IC Type:

    CONSUMER CIRCUIT

  • JESD-30 Code:

    S-XQCC-N28

  • JESD-609 Code:

    e3

  • Length:

    5 mm

  • Moisture Sensitivity Level:

    3

  • Number of Functions:

    1

  • Number of Terminals:

    28

  • Operating Temperature-Max:

    70 °C

  • Operating Temperature-Min:

    -10 °C

  • Package Body Material:

    UNSPECIFIED

  • Package Code:

    HVQCCN

  • Package Equivalence Code:

    LCC28,.2SQ,20

  • Package Shape:

    SQUARE

  • Package Style:

    CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

  • Peak Reflow Temperature (Cel):

    260

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    1 mm

  • Supply Voltage-Max (Vsup):

    3.46 V

  • Supply Voltage-Min (Vsup):

    3.13 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    COMMERCIAL

  • Terminal Finish:

    Matte Tin (Sn)

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    QUAD

  • Width:

    5 mm

CS8416-CNZ Frequently Asked Questions (FAQs)

  • The recommended power-up sequence is to apply VCC first, followed by VDD, and then the clock signal. This ensures proper initialization of the device.
  • To configure the CS8416-CNZ for master clock mode, set the MCKE pin high and the MCKI pin low. This enables the internal clock generator and allows the device to generate the master clock signal.
  • The CS8416-CNZ supports clock frequencies up to 192 kHz. However, the maximum clock frequency may vary depending on the specific application and system requirements.
  • To implement jitter reduction on the CS8416-CNZ, use the device's built-in jitter reduction circuitry by setting the JR pin high. This enables the jitter reduction feature and helps to reduce clock jitter.
  • The CS8416-CNZ's PLL (Phase-Locked Loop) is used to generate a stable clock signal from an external clock source. The PLL helps to reduce jitter and ensure a stable clock signal for the device.
