CSD75204W15 - Texas Instruments

CSD75204W15 Details

• Manufacturer Part Number:

  CSD75204W15

• Brand Name:

  Texas Instruments

• Pbfree Code:

  No

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  1.50 X 1.50 MM, HALOGEN FREE AND ROHS COMPLIANT PACKAGE-9

• Pin Count:

  9

• ECCN Code:

  EAR99

• Manufacturer:

  Texas Instruments

• YTEOL:

  0

• Configuration:

  COMMON SOURCE, 2 ELEMENTS WITH BUILT-IN DIODE AND RESISTOR

• Drain Current-Max (ID):

  3 A

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  55 pF

• JESD-30 Code:

  S-XBGA-B9

• Number of Elements:

  2

• Number of Terminals:

  9

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  150 °C

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Polarity/Channel Type:

  P-CHANNEL

• Power Dissipation-Max (Abs):

  0.7 W

• Qualification Status:

  Not Qualified

• Surface Mount:

  YES

• Terminal Form:

  BALL

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
