DMA2610M0R - Panasonic

DMA2610M0R Details

• Manufacturer Part Number:

  DMA2610M0R

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  HALOGEN FREE AND ROHS COMPLIANT, MINI5-G3-B, MO-178, SC-74A, 5 PIN

• ECCN Code:

  EAR99

• Manufacturer:

  Panasonic Electronic Components

• Additional Feature:

  BUILT IN BIAS RESISTOR RATIO 21.36

• Collector Current-Max (IC):

  0.1 A

• Collector-Emitter Voltage-Max:

  50 V

• Configuration:

  COMMON EMITTER, 2 ELEMENTS WITH BUILT-IN RESISTOR

• DC Current Gain-Min (hFE):

  80

• JEDEC-95 Code:

  MO-178AA

• JESD-30 Code:

  R-PDSO-G5

• Number of Elements:

  2

• Number of Terminals:

  5

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Polarity/Channel Type:

  PNP

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
