DMG564H30R - Panasonic

DMG564H30R Details

• Manufacturer Part Number:

  DMG564H30R

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  HALOGEN FREE AND ROHS COMPLIANT, SMINI6-F3-B, SC-113DB, 6 PIN

• ECCN Code:

  EAR99

• Manufacturer:

  Panasonic Electronic Components

• Additional Feature:

  BUILT IN BIAS RESISTOR RATIO 10

• Collector Current-Max (IC):

  0.1 A

• Collector-Emitter Voltage-Max:

  50 V

• Configuration:

  SEPARATE, 2 ELEMENTS WITH BUILT-IN RESISTOR

• DC Current Gain-Min (hFE):

  80

• JESD-30 Code:

  R-PDSO-F6

• Number of Elements:

  2

• Number of Terminals:

  6

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Polarity/Channel Type:

  NPN AND PNP

• Power Dissipation-Max (Abs):

  0.15 W

• Surface Mount:

  YES

• Terminal Form:

  FLAT

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
