DP83849CVS - Texas Instruments

DP83849CVS Details

• Manufacturer Part Number:

  DP83849CVS

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  QFP

• Package Description:

  12 X 12 MM, TQFP-80

• Pin Count:

  80

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Texas Instruments

• YTEOL:

  0

• Data Rate:

  100000 Mbps

• JESD-30 Code:

  S-PQFP-G80

• Length:

  12 mm

• Number of Functions:

  1

• Number of Terminals:

  80

• Number of Transceivers:

  2

• Operating Temperature-Max:

  70 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TFQFP

• Package Equivalence Code:

  TQFP80,.55SQ

• Package Shape:

  SQUARE

• Package Style:

  FLATPACK, THIN PROFILE, FINE PITCH

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  1.2 mm

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Telecom IC Type:

  ETHERNET TRANSCEIVER

• Temperature Grade:

  COMMERCIAL

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Width:

  12 mm
