DP83865DVH - Texas Instruments

Description: Ethernet Physical Layer,DP83865DVH

Download DP83865DVH Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
DP83865DVH - Texas Instruments - PCB symbol
click to zoom
PCB Footprints
DP83865DVH - Texas Instruments PCB footprint - Quad Flat Packages - Quad Flat Packages - 128 Lead Plastic Flat Pack
click to zoom
3D Models
DP83865DVH - Texas Instruments - 3D model - Quad Flat Packages - 128 Lead Plastic Flat Pack
click to zoom

DP83865DVH Details

  • Manufacturer Part Number:

    DP83865DVH

  • Brand Name:

    Texas Instruments

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    QFP

  • Pin Count:

    128

  • ECCN Code:

    5A991.B

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    0

  • Data Rate:

    1000000 Mbps

  • JESD-30 Code:

    R-PQFP-G128

  • JESD-609 Code:

    e0

  • Length:

    20 mm

  • Moisture Sensitivity Level:

    3

  • Number of Functions:

    1

  • Number of Terminals:

    128

  • Number of Transceivers:

    1

  • Operating Temperature-Max:

    70 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    FQFP

  • Package Equivalence Code:

    QFP128,.67X.93,20

  • Package Shape:

    RECTANGULAR

  • Package Style:

    FLATPACK, FINE PITCH

  • Peak Reflow Temperature (Cel):

    245

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    3.15 mm

  • Supply Voltage-Nom:

    1.8 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Telecom IC Type:

    ETHERNET TRANSCEIVER

  • Temperature Grade:

    COMMERCIAL

  • Terminal Finish:

    Tin/Lead (Sn/Pb)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    QUAD

  • Width:

    14 mm

DP83865DVH Frequently Asked Questions (FAQs)
