DRV10970PWPR - Texas Instruments

Description: 20W, 12V 3-phase sensored BLDC motor driver with single/3halls supported

Download DRV10970PWPR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
DRV10970PWPR - Texas Instruments - PCB symbol
click to zoom
PCB Footprints
DRV10970PWPR - Texas Instruments PCB footprint - Small Outline Packages - Small Outline Packages - PWP (R-PDSO-G24)_3
click to zoom
3D Models
DRV10970PWPR - Texas Instruments - 3D model - Small Outline Packages - PWP (R-PDSO-G24)_3
click to zoom

DRV10970PWPR Details

  • Manufacturer Part Number:

    DRV10970PWPR

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Taiwan

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.90

  • Date Of Intro:

    2016-03-15

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    15

  • Analog IC - Other Type:

    3-PHASE BRUSHLESS DC MOTOR CONTROLLER

  • JESD-30 Code:

    R-PDSO-G24

  • JESD-609 Code:

    e4

  • Length:

    7.8 mm

  • Moisture Sensitivity Level:

    2

  • Number of Functions:

    1

  • Number of Terminals:

    24

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Current-Max:

    2 A

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HTSSOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    1.2 mm

  • Supply Current-Max (Isup):

    5 mA

  • Supply Voltage-Max (Vsup):

    18 V

  • Supply Voltage-Min (Vsup):

    5 V

  • Supply Voltage-Nom (Vsup):

    12 V

  • Surface Mount:

    YES

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    4.4 mm

DRV10970PWPR Frequently Asked Questions (FAQs)

  • A good PCB layout for the DRV10970PWPR involves keeping the high-current paths short and wide, using a solid ground plane, and placing the device close to the motor. TI provides a recommended PCB layout in the datasheet and application notes.
  • The sense resistor value depends on the motor current and the desired current sense accuracy. A smaller sense resistor value provides better accuracy but increases the power loss. TI provides a sense resistor calculation tool and guidelines in the datasheet.
  • The DRV10970PWPR has an operating temperature range of -40°C to 125°C. However, the device's performance and reliability may degrade at extreme temperatures. It's essential to ensure proper thermal management and heat sinking.
  • The DRV10970PWPR has built-in overvoltage protection (OVP) and undervoltage protection (UVP). However, additional external protection circuits may be necessary depending on the application. TI recommends using a voltage regulator and TVS diodes for added protection.
  • A 10uF to 22uF decoupling capacitor is recommended, placed as close as possible to the device's power pins. This helps to filter out noise and reduce electromagnetic interference (EMI).
