DRV2700RGPR - Texas Instruments

Description: DRV2700 High Voltage Driver with Integrated Boost Converter

Download DRV2700RGPR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
DRV2700RGPR - Texas Instruments - PCB symbol
click to zoom
PCB Footprints
DRV2700RGPR - Texas Instruments PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - QFN_20
click to zoom
3D Models
DRV2700RGPR - Texas Instruments - 3D model - Quad Flat No-Lead - QFN_20
click to zoom

DRV2700RGPR Details

  • Manufacturer Part Number:

    DRV2700RGPR

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Philippines

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.90

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    15

  • Analog IC - Other Type:

    ANALOG CIRCUIT

  • JESD-30 Code:

    S-PQCC-N20

  • JESD-609 Code:

    e4

  • Length:

    4 mm

  • Moisture Sensitivity Level:

    1

  • Number of Channels:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    20

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Voltage-Max:

    200 V

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HVQCCN

  • Package Shape:

    SQUARE

  • Package Style:

    CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    1 mm

  • Supply Voltage-Max (Vsup):

    5.5 V

  • Supply Voltage-Min (Vsup):

    3 V

  • Supply Voltage-Nom (Vsup):

    3.6 V

  • Surface Mount:

    YES

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    QUAD

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    4 mm

DRV2700RGPR Frequently Asked Questions (FAQs)

  • A good PCB layout for the DRV2700RGPR involves keeping the high-current paths short and wide, using a solid ground plane, and placing the device close to the motor. TI provides a recommended PCB layout in the datasheet and application notes.
  • The sense resistor value depends on the motor current and the desired current sense accuracy. A general guideline is to choose a sense resistor that limits the voltage across it to 50-100 mV at the maximum motor current. TI provides a sense resistor calculation tool to help with this.
  • The internal bootstrap diode is used to generate the high-side gate drive voltage. It eliminates the need for an external bootstrap diode and reduces the component count. However, it also means that the high-side gate drive voltage is limited to VCC + 0.5 V, which may affect the design of the power stage.
  • The DRV2700RGPR has a built-in overcurrent protection feature that can be enabled by connecting the OCP pin to a resistor divider network. The device also has a fault detection pin that can be used to detect overcurrent, overtemperature, and undervoltage conditions. TI provides guidelines for implementing these features in the datasheet and application notes.
  • The DRV2700RGPR can operate up to 100 kHz, but the maximum operating frequency depends on the specific application and motor characteristics. TI recommends evaluating the device's performance at the desired frequency and ensuring that it meets the application's requirements.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

DRV2700RGPR Overview

Use the download button to access the DRV2700RGPR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like DRV27, or try a keyword search, such as Other Signal Circuits

About Texas Instruments

Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
