DRV5053CAQLPGM - Texas Instruments

DRV5053CAQLPGM Details

• Manufacturer Part Number:

  DRV5053CAQLPGM

• Brand Name:

  Texas Instruments

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  TO-92-3

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.90

• Manufacturer:

  Texas Instruments

• YTEOL:

  15

• Additional Feature:

  SHORT CIRCUIT PROTECTION, IT HAS SENSITIVITY OF 23 MV/MT

• Body Breadth:

  1.52 mm

• Body Height:

  3.15 mm

• Body Length or Diameter:

  4 mm

• Housing:

  PLASTIC

• Input Mode:

  BIPOLAR

• JESD-609 Code:

  e3

• Linearity (%):

  1 %

• Mounting Feature:

  THROUGH HOLE MOUNT

• Number of Terminals:

  3

• Operating Current-Max:

  3.6 mA

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  2.3 mA

• Output Polarity:

  COMPLEMENTARY

• Output Range:

  0-2V

• Output Type:

  ANALOG VOLTAGE

• Package Equivalence Code:

  SIP3,.1,50

• Package Shape/Style:

  RECTANGULAR

• Packing Method:

  AMMO PACK

• Screening Level:

  AEC-Q100

• Sensitivity (mV/G):

  230 mV/G

• Sensors/Transducers Type:

  MAGNETIC FIELD SENSOR,HALL EFFECT

• Supply Voltage-Max:

  38 V

• Supply Voltage-Min:

  2.5 V

• Surface Mount:

  NO

• Terminal Finish:

  Matte Tin (Sn) - annealed

• Termination Type:

  SOLDER
