The recommended PCB footprint for EKMG350ELL101MF11D is a rectangular pad with dimensions of 10.2mm x 7.4mm, with a 0.5mm radius corner and a 0.3mm hole diameter for the terminal.
Yes, the EKMG350ELL101MF11D is designed to withstand high-vibration environments. It has a vibration resistance of 10Hz to 2000Hz, 10G acceleration, and a shock resistance of 3000G, 3ms duration.
Yes, the EKMG350ELL101MF11D is AEC-Q200 qualified, which means it meets the stringent requirements for automotive applications, including high temperatures, vibrations, and humidity.
The derating curve for EKMG350ELL101MF11D is typically provided by Chemi-Con upon request. However, as a general guideline, the capacitor's voltage rating should be derated by 1.25% per degree Celsius above 85°C.
Yes, the EKMG350ELL101MF11D is designed to operate up to 2000m above sea level. However, it's recommended to consult with Chemi-Con for specific guidance on high-altitude applications.
