F4-23MR12W1M1P_B11 - Infineon

F4-23MR12W1M1P_B11 Details

• Manufacturer Part Number:

  F4-23MR12W1M1P_B11

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  MODULE-16

• ECCN Code:

  EAR99

• Manufacturer:

  Infineon Technologies AG

• YTEOL:

  0

• Case Connection:

  ISOLATED

• Configuration:

  BRIDGE, 4 ELEMENTS WITH BUILT-IN DIODE AND THERMISTOR

• DS Breakdown Voltage-Min:

  1200 V

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  28 pF

• JESD-30 Code:

  R-XUFM-X16

• Number of Elements:

  4

• Number of Terminals:

  16

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  0.02 W

• Surface Mount:

  NO

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UPPER

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON CARBIDE
