F4-75R07W1H3_B11A - Infineon

F4-75R07W1H3_B11A Details

• Manufacturer Part Number:

  F4-75R07W1H3_B11A

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  ,

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• Manufacturer:

  Infineon Technologies AG

• YTEOL:

  0

• Case Connection:

  ISOLATED

• Collector Current-Max (IC):

  75 A

• Collector-Emitter Voltage-Max:

  650 V

• Configuration:

  COMPLEX

• Gate-Emitter Thr Voltage-Max:

  6.5 V

• Gate-Emitter Voltage-Max:

  20 V

• JESD-30 Code:

  R-XUFM-X20

• Number of Elements:

  4

• Number of Terminals:

  20

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  275 W

• Reference Standard:

  UL APPROVED

• Surface Mount:

  NO

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UPPER

• Transistor Application:

  POWER CONTROL

• Transistor Element Material:

  SILICON

• Turn-off Time-Nom (toff):

  213 ns

• Turn-on Time-Nom (ton):

  32 ns

• VCEsat-Max:

  1.85 V
