Part Image

FDA2100BLV-T - STMicroelectronics

Description: 2 x 180 W / 1 x 300 W PWM digital input automotive power amplifier with built-in diagnostics features and step-up drive

Download FDA2100BLV-T Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
FDA2100BLV-T - STMicroelectronics - PCB symbol
click to zoom
PCB Footprints
FDA2100BLV-T - STMicroelectronics PCB footprint - Quad Flat Packages - Quad Flat Packages - TQFP64 (10x10x1 mm exp. pad down)
click to zoom
3D Models
FDA2100BLV-T - STMicroelectronics - 3D model - Quad Flat Packages - TQFP64 (10x10x1 mm exp. pad down)
click to zoom

FDA2100BLV-T Details

  • Manufacturer Part Number:

    FDA2100BLV-T

  • Brand Name:

    STMicroelectronics

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Not Recommended

  • Package Description:

    TQFP-64

  • Manufacturer Package Code:

    TQFP 64 10x10x1.0

  • Country Of Origin:

    Malaysia

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.33.00.01

  • Factory Lead Time:

    26 Weeks

  • Manufacturer:

    STMicroelectronics

  • YTEOL:

    3

  • Consumer IC Type:

    CLASS D AUDIO AMPLIFIER

  • JESD-30 Code:

    S-PQFP-G64

  • Length:

    10 mm

  • Moisture Sensitivity Level:

    3

  • Number of Channels:

    2

  • Number of Functions:

    1

  • Number of Terminals:

    64

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HTFQFP

  • Package Equivalence Code:

    TQFP64,.47SQ

  • Package Shape:

    SQUARE

  • Package Style:

    FLATPACK, HEAT SINK/SLUG, THIN PROFILE, FINE PITCH

  • Screening Level:

    AEC-Q100

  • Seated Height-Max:

    1.2 mm

  • Supply Voltage-Max (Vsup):

    35 V

  • Supply Voltage-Min (Vsup):

    6 V

  • Surface Mount:

    YES

  • Technology:

    BCDMOS

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    QUAD

  • Width:

    10 mm

FDA2100BLV-T Frequently Asked Questions (FAQs)

  • A good PCB layout for the FDA2100BLV-T involves keeping the analog and digital grounds separate, using a solid ground plane, and minimizing the length of the input traces to reduce noise and interference.
  • To ensure proper biasing, connect the VCC pin to a stable 3.3V or 5V power supply, and decouple it with a 10uF capacitor to ground. Also, ensure the input voltage is within the recommended range of 0.5V to 2.5V.
  • The FDA2100BLV-T requires a low-pass filter or a voltage divider to condition the input signal. A 1kΩ resistor and a 10nF capacitor in series can be used to filter out high-frequency noise.
  • The FDA2100BLV-T outputs a differential signal, which can be converted to a single-ended signal using an op-amp or a dedicated differential-to-single-ended converter. Alternatively, use a differential receiver or a dedicated ADC with differential inputs.
  • The FDA2100BLV-T is rated for operation from -40°C to 125°C, but the device's performance may degrade at extreme temperatures. Ensure proper thermal management and consider derating the device for high-temperature applications.

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

FDA2100BLV-T Overview

Use the download button to access the FDA2100BLV-T schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like FDA21, or try a keyword search, such as Audio/Video Amplifiers

About STMicroelectronics

STMicroelectronics (ST) is a global semiconductor company that designs, manufactures, and markets a broad range of integrated circuits (ICs), discrete devices, and other electronic components. STMicroelectronics offers a diverse portfolio of semiconductor products covering a wide range of applications and industries. Their product categories include microcontrollers, analog and mixed-signal ICs, MEMS (Micro-Electro-Mechanical Systems) sensors, power management ICs, RF (Radio Frequency) transceivers, aut
