The thermal resistance (Rth) of the FS3L50R07W2H3FB11BPSA1 is typically around 1.5 K/W (junction-to-case) and 3.5 K/W (junction-to-ambient) at a maximum junction temperature of 175°C.
To ensure reliability, follow the recommended operating conditions, use a suitable thermal management system, and consider derating the device's power handling capabilities at high temperatures. Additionally, ensure proper PCB design, layout, and soldering to minimize thermal resistance and prevent hotspots.
The recommended gate drive voltage for the FS3L50R07W2H3FB11BPSA1 is between 10 V and 15 V, with a maximum gate-source voltage of ±20 V. A higher gate drive voltage can improve switching performance, but may also increase power losses and EMI.
Yes, the FS3L50R07W2H3FB11BPSA1 can be used in a parallel configuration to increase power handling. However, it's essential to ensure that the devices are properly matched, and the gate drive signals are synchronized to prevent uneven current sharing and potential oscillations.
The maximum allowed voltage overshoot for the FS3L50R07W2H3FB11BPSA1 is typically around 10% of the maximum drain-source voltage (Vds) rating, which is 650 V for this device. This means the maximum allowed voltage overshoot is around 65 V.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
FS3L50R07W2H3FB11BPSA1 Overview
Use the download button to access the FS3L50R07W2H3FB11BPSA1 schematic symbol and PCB footprint.
To find more CAD model downloads similar to this part, try a partial part number search, like FS3L5,
or try a keyword search, such as IGBTs
