HCPL4502 - Texas Instruments

HCPL4502 Details

• Manufacturer Part Number:

  HCPL4502

• Brand Name:

  Texas Instruments

• Pbfree Code:

  No

• Rohs Code:

  No

• Part Life Cycle Code:

  Obsolete

• Package Description:

  PLASTIC, DIP-8

• Reach Compliance Code:

  Not Compliant

• HTS Code:

  8541.40.80.00

• Manufacturer:

  Texas Instruments

• YTEOL:

  0

• Additional Feature:

  UL RECOGNIZED, TTL COMPATIBLE, OPEN COLLECTOR

• Configuration:

  SINGLE

• Data Rate-Nom:

  1 MBps

• Forward Current-Max:

  0.025 A

• Isolation Voltage-Max:

  3000 V

• Mounting Feature:

  THROUGH HOLE MOUNT

• Number of Elements:

  1

• Number of Functions:

  1

• On-State Current-Max:

  0.008 A

• Operating Temperature-Max:

  70 °C

• Optoelectronic Device Type:

  LOGIC IC OUTPUT OPTOCOUPLER

• Response Time-Max:

  8e-7 s

• Response Time-Nom:

  6e-7 ns

• Supply Voltage-Min:

  5 V

• Surface Mount:

  NO
