HD1-6402B/883 - Renesas Electronics

HD1-6402B/883 Details

• Manufacturer Part Number:

  HD1-6402B/883

• Brand Name:

  Renesas

• Pbfree Code:

  No

• Part Life Cycle Code:

  Active

• Part Package Code:

  CERDIP

• Package Description:

  CERDIP-40

• Pin Count:

  40

• Manufacturer Package Code:

  F40.6

• Country Of Origin:

  Philippines, Thailand

• HTS Code:

  8542.31.00.30

• Factory Lead Time:

  18 Weeks

• Date Of Intro:

  2018-07-18

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  4

• Boundary Scan:

  NO

• Bus Compatibility:

  UART

• Clock Frequency-Max:

  8 MHz

• Communication Protocol:

  ASYNC, BIT

• JESD-30 Code:

  R-CDIP-T40

• JESD-609 Code:

  e0

• Length:

  53.24 mm

• Low Power Mode:

  YES

• Number of Terminals:

  40

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Code:

  DIP

• Package Equivalence Code:

  DIP40,.6

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Screening Level:

  MIL-STD-883

• Seated Height-Max:

  5.72 mm

• Supply Current-Max:

  2 mA

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  4.5 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  NO

• Technology:

  CMOS

• Temperature Grade:

  MILITARY

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Width:

  15.24 mm

• uPs/uCs/Peripheral ICs Type:

  SERIAL IO/COMMUNICATION CONTROLLER, SERIAL
