HFA3127BZ - Renesas Electronics

HFA3127BZ Details

• Manufacturer Part Number:

  HFA3127BZ

• Brand Name:

  Renesas

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SOICN

• Package Description:

  SOIC-16

• Pin Count:

  16

• Manufacturer Package Code:

  M16.15

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Additional Feature:

  LOW NOISE

• Collector Current-Max (IC):

  0.037 A

• Collector-Base Capacitance-Max:

  0.2 pF

• Collector-Emitter Voltage-Max:

  8 V

• Configuration:

  SEPARATE, 5 ELEMENTS

• DC Current Gain-Min (hFE):

  40

• Highest Frequency Band:

  ULTRA HIGH FREQUENCY BAND

• JEDEC-95 Code:

  MS-012AC

• JESD-30 Code:

  R-PDSO-G16

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  3

• Number of Elements:

  5

• Number of Terminals:

  16

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  NPN

• Power Dissipation-Max (Abs):

  0.15 W

• Surface Mount:

  YES

• Terminal Finish:

  Matte Tin (Sn) - annealed

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30

• Transistor Application:

  AMPLIFIER

• Transistor Element Material:

  SILICON

• Transition Frequency-Nom (fT):

  8000 MHz
