HSP50415VIZ footprint, schematic symbol and 3D model by Renesas Electronics

HSP50415VIZ - Renesas Electronics

Description: The HSP50415 Wideband Programmable Modulator (WPM) is a quadrature amplitude modulator/upconverter designed for wideband digital modulation. The WPM combines shaping and interpolation filters, a complex modulator, timing and carrier NCOs and dual DACs into a single package. The HSP50415 supports vector modulation, accepting up to 16-bit In phase (I) and Quadrature (Q) samples to generate virtually any quadrature AM or PM modulation format. A constellation mapper and 24 Symbol span interpolation shaping filt

Download HSP50415VIZ Model

Schematic
symbols

PCB
footprints

3D
models

Symbol

click to zoom

PCB Footprints

HSP50415VIZ - Renesas Electronics PCB footprint - Quad Flat Packages - Quad Flat Packages - 100 Ld MQFP (Pb-free)

click to zoom

3D Models

HSP50415VIZ - Renesas Electronics - 3D model - Quad Flat Packages - 100 Ld MQFP (Pb-free)

click to zoom

Datasheet Download Datasheet
Stock & Prices Price & Stock for HSP50415VIZ
Part Number HSP50415VIZ
Manufacturer Renesas Electronics
Pin Count 100
Part Category Integrated Circuit
Package Category Quad Flat Packages
Footprint Name Quad Flat Packages - 100 Ld MQFP (Pb-free)
Released Date Dec 18, 2019
Last Modified Date Oct 24, 2023 7:30 PM UTC
Pinout / Pin List Click Here (Member Only)

HSP50415VIZ Details

Manufacturer Part Number:
HSP50415VIZ
Manufacturer:
Renesas Electronics Corporation

Trust Checks

Manufacturer Collaborated

System Verified

Community Approved

HSP50415VIZ Overview

Use the download button to access the HSP50415VIZ schematic symbol, PCB footprint, and 3D model.

To find more CAD model downloads similar to this part, try a partial part number search, like HSP50, or try a keyword search, such as Other Telecom ICs
