ICE40LM4K-SWG25TR1K - Lattice Semiconductor

ICE40LM4K-SWG25TR1K Details

• Manufacturer Part Number:

  ICE40LM4K-SWG25TR1K

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  WLCSP-25

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Lattice Semiconductor Corporation

• YTEOL:

  0

• Clock Frequency-Max:

  85.25 MHz

• Combinatorial Delay of a CLB-Max:

  9.1 ns

• JESD-30 Code:

  S-PBGA-B25

• Length:

  1.71 mm

• Number of CLBs:

  440

• Number of Inputs:

  18

• Number of Logic Cells:

  3520

• Number of Outputs:

  18

• Number of Terminals:

  25

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  440 CLBS

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  VFBGA

• Package Equivalence Code:

  BGA25,5X5,14

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, VERY THIN PROFILE, FINE PITCH

• Packing Method:

  TR

• Programmable Logic Type:

  FIELD PROGRAMMABLE GATE ARRAY

• Seated Height-Max:

  0.491 mm

• Supply Voltage-Max:

  1.26 V

• Supply Voltage-Min:

  1.14 V

• Supply Voltage-Nom:

  1.2 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  BALL

• Terminal Pitch:

  0.35 mm

• Terminal Position:

  BOTTOM

• Width:

  1.71 mm
