ICE5LP4K-SWG36ITR50 - Lattice Semiconductor

Description: FPGA iCE40 Ultra Family 3520 Cells 40nm Technology 1.2V 36-Pin WLCSP T/R

Download ICE5LP4K-SWG36ITR50 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
ICE5LP4K-SWG36ITR50 - Lattice Semiconductor PCB footprint - BGA - BGA - 36-Ball WLCS Package Option 1: iCE40 Ultra
click to zoom
3D Models
ICE5LP4K-SWG36ITR50 - Lattice Semiconductor  - 3D model - BGA - 36-Ball WLCS Package Option 1: iCE40 Ultra
click to zoom

ICE5LP4K-SWG36ITR50 Details

  • Manufacturer Part Number:

    ICE5LP4K-SWG36ITR50

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    Lattice Semiconductor Corporation

  • YTEOL:

    0

  • Combinatorial Delay of a CLB-Max:

    9 ns

  • JESD-30 Code:

    S-PBGA-B36

  • Length:

    2.078 mm

  • Moisture Sensitivity Level:

    1

  • Number of CLBs:

    440

  • Number of Inputs:

    26

  • Number of Logic Cells:

    3520

  • Number of Outputs:

    26

  • Number of Terminals:

    36

  • Operating Temperature-Max:

    100 °C

  • Operating Temperature-Min:

    -40 °C

  • Organization:

    440 CLBS

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    VFBGA

  • Package Equivalence Code:

    BGA36,6X6,14

  • Package Shape:

    SQUARE

  • Package Style:

    GRID ARRAY, VERY THIN PROFILE, FINE PITCH

  • Packing Method:

    TR

  • Peak Reflow Temperature (Cel):

    260

  • Programmable Logic Type:

    FIELD PROGRAMMABLE GATE ARRAY

  • Seated Height-Max:

    0.491 mm

  • Supply Voltage-Max:

    1.26 V

  • Supply Voltage-Min:

    1.14 V

  • Supply Voltage-Nom:

    1.2 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Form:

    BALL

  • Terminal Pitch:

    0.35 mm

  • Terminal Position:

    BOTTOM

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    2.078 mm

ICE5LP4K-SWG36ITR50 Frequently Asked Questions (FAQs)

  • The maximum operating frequency of the ICE5LP4K-SWG36ITR50 FPGA is 150 MHz.
  • To implement a CDC in the ICE5LP4K-SWG36ITR50, use the built-in clock domain crossing (CDC) circuitry and follow the guidelines outlined in the Lattice Semiconductor Corporation's CDC user guide.
  • The power consumption of the ICE5LP4K-SWG36ITR50 FPGA varies depending on the operating frequency, voltage, and usage. Refer to the datasheet for typical power consumption values and use the Lattice Semiconductor Corporation's Power Calculator tool for more accurate estimates.
  • The ICE5LP4K-SWG36ITR50 FPGA is not specifically designed for radiation-hardened environments. For such applications, consider using a radiation-hardened FPGA from Lattice Semiconductor Corporation or other manufacturers.
  • To secure your design on the ICE5LP4K-SWG36ITR50 FPGA, use the built-in security features such as the Secure Configuration and Encryption (SCE) and the TransFR Interface. Additionally, follow secure design practices and guidelines outlined in the Lattice Semiconductor Corporation's security documentation.
