ILD620GB - Vishay

Description: Vishay ILD620GB AC Input Phototransistor Output Dual Optocoupler, Through Hole, 8-Pin DIP

Download ILD620GB Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
ILD620GB - Vishay PCB footprint - Dual-In-Line Packages - Dual-In-Line Packages - DIP8*
click to zoom
3D Models
ILD620GB - Vishay  - 3D model - Dual-In-Line Packages - DIP8*
click to zoom

ILD620GB Details

  • Manufacturer Part Number:

    ILD620GB

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • ECCN Code:

    EAR99

  • HTS Code:

    8541.40.80.00

  • Manufacturer:

    Vishay Intertechnologies

  • YTEOL:

    0

  • Coll-Emtr Bkdn Voltage-Min:

    70 V

  • Configuration:

    SEPARATE, 2 CHANNELS

  • Current Transfer Ratio-Nom:

    200%

  • Dark Current-Max:

    100 nA

  • Forward Current-Max:

    0.06 A

  • Isolation Voltage-Max:

    5300 V

  • JESD-609 Code:

    e3

  • Number of Elements:

    2

  • Operating Temperature-Max:

    100 °C

  • Operating Temperature-Min:

    -55 °C

  • Optoelectronic Device Type:

    AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER

  • Terminal Finish:

    Matte Tin (Sn)
