L99DZ70XPTR - STMicroelectronics

Description: IC DOOR ACTUATOR DRVR POWERSSO36

Download L99DZ70XPTR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
L99DZ70XPTR - STMicroelectronics - PCB symbol
click to zoom
PCB Footprints
L99DZ70XPTR - STMicroelectronics PCB footprint - Small Outline Packages - Small Outline Packages - PowerSSO-36---
click to zoom
3D Models
L99DZ70XPTR - STMicroelectronics - 3D model - Small Outline Packages - PowerSSO-36---
click to zoom

L99DZ70XPTR Details

  • Manufacturer Part Number:

    L99DZ70XPTR

  • Brand Name:

    STMicroelectronics

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    SSOP

  • Package Description:

    SSO-36

  • Pin Count:

    36

  • Country Of Origin:

    Malaysia

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    23 Weeks

  • Manufacturer:

    STMicroelectronics

  • YTEOL:

    9

  • Analog IC - Other Type:

    DOOR MODULE DRIVERS

  • JESD-30 Code:

    R-PDSO-G36

  • JESD-609 Code:

    e3

  • Length:

    10.3 mm

  • Moisture Sensitivity Level:

    3

  • Number of Functions:

    1

  • Number of Terminals:

    36

  • Operating Temperature-Max:

    150 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Current-Max:

    6 A

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HSSOP

  • Package Equivalence Code:

    SSOP36,.4,20

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, HEAT SINK/SLUG, SHRINK PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    2.45 mm

  • Supply Current-Max (Isup):

    20 mA

  • Supply Voltage-Max (Vsup):

    28 V

  • Supply Voltage-Min (Vsup):

    7 V

  • Supply Voltage-Nom (Vsup):

    8 V

  • Surface Mount:

    YES

  • Terminal Finish:

    Matte Tin (Sn) - annealed

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    7.5 mm

L99DZ70XPTR Frequently Asked Questions (FAQs)

  • STMicroelectronics provides a recommended PCB layout in the application note AN4841, which includes guidelines for component placement, routing, and thermal management.
  • The L99DZ70XPTR can be configured for different vehicle protocols such as CAN, LIN, and SAE J1850 using the STMicroelectronics software development kit (SDK) and the device's registers. Refer to the device's programming manual for more information.
  • The L99DZ70XPTR has an operating temperature range of -40°C to 125°C, but the maximum junction temperature (TJ) should not exceed 150°C to ensure reliable operation.
  • To troubleshoot communication issues, check the device's configuration, clock settings, and bus termination. Use a logic analyzer or oscilloscope to verify signal integrity and timing. Consult the device's datasheet and application notes for more troubleshooting tips.
  • While the L99DZ70XPTR is designed for automotive applications, it can be used in other applications that require a high-speed transceiver with advanced features. However, ensure that the device meets the specific requirements of your application, including operating temperature, voltage, and protocol support.
