LM2679T-12/NOPB - Texas Instruments

Description: Switching Voltage Regulators 5A SD VTG Reg

Download LM2679T-12/NOPB Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
LM2679T-12/NOPB - Texas Instruments - PCB symbol
click to zoom
PCB Footprints
LM2679T-12/NOPB - Texas Instruments PCB footprint - Transistor Outline, Vertical - Transistor Outline, Vertical - NDZ0007B
click to zoom
3D Models
LM2679T-12/NOPB - Texas Instruments - 3D model - Transistor Outline, Vertical - NDZ0007B
click to zoom

LM2679T-12/NOPB Details

  • Manufacturer Part Number:

    LM2679T-12/NOPB

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.90

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    15

  • Analog IC - Other Type:

    SWITCHING REGULATOR

  • Control Mode:

    VOLTAGE-MODE

  • Control Technique:

    PULSE WIDTH MODULATION

  • Input Voltage-Max:

    40 V

  • Input Voltage-Min:

    8 V

  • Input Voltage-Nom:

    24 V

  • JESD-30 Code:

    R-XZFM-T7

  • JESD-609 Code:

    e3

  • Length:

    14.986 mm

  • Moisture Sensitivity Level:

    1

  • Number of Functions:

    1

  • Number of Outputs:

    1

  • Number of Terminals:

    7

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Current-Max:

    5 A

  • Output Voltage-Max:

    37 V

  • Output Voltage-Min:

    1.23 V

  • Output Voltage-Nom:

    12 V

  • Package Body Material:

    UNSPECIFIED

  • Package Code:

    ZIP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    FLANGE MOUNT

  • Seated Height-Max:

    4.7 mm

  • Surface Mount:

    NO

  • Switcher Configuration:

    BUCK

  • Switching Frequency-Max:

    260 kHz

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Finish:

    Matte Tin (Sn)

  • Terminal Form:

    THROUGH-HOLE

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    ZIG-ZAG

  • Width:

    10.16 mm

LM2679T-12/NOPB Frequently Asked Questions (FAQs)

  • The maximum input voltage that can be applied to the LM2679T-12/NOPB is 40V, but it's recommended to keep it below 30V for reliable operation.
  • The LM2679T-12/NOPB has a maximum operating junction temperature of 150°C, but it's recommended to keep it below 125°C for reliable operation. You may need to consider thermal management and derating for high-temperature applications.
  • To ensure the stability of the output voltage, make sure to use the recommended output capacitor value and type, and keep the output capacitor close to the device. Also, ensure that the input voltage is within the recommended range and the device is operated within its specified temperature range.
  • Yes, the LM2679T-12/NOPB is a switching regulator and can be used in a switching mode power supply. However, you need to ensure that the input voltage is within the recommended range and the device is operated within its specified temperature range.
  • The minimum input voltage required for the LM2679T-12/NOPB to operate is 7.5V, but it's recommended to keep it above 10V for reliable operation.
