LM383AT - Texas Instruments

LM383AT Details

• Manufacturer Part Number:

  LM383AT

• Rohs Code:

  No

• Part Life Cycle Code:

  Obsolete

• Package Description:

  TO-220, ZIP5,.15,.2,67TB

• Reach Compliance Code:

  Unknown

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Manufacturer:

  Texas Instruments

• YTEOL:

  0

• Bandwidth-Nom:

  30 kHz

• Consumer IC Type:

  AUDIO AMPLIFIER

• Harmonic Distortion:

  0.2%

• JESD-30 Code:

  R-PSFM-T5

• JESD-609 Code:

  e0

• Number of Channels:

  1

• Number of Functions:

  1

• Number of Terminals:

  5

• Operating Temperature-Max:

  70 °C

• Output Power-Nom:

  11 W

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TO-220

• Package Equivalence Code:

  ZIP5,.15,.2,67TB

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Qualification Status:

  Not Qualified

• Supply Current-Max:

  80 mA

• Supply Voltage-Max (Vsup):

  20 V

• Supply Voltage-Min (Vsup):

  5 V

• Surface Mount:

  NO

• Technology:

  BIPOLAR

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  1.7 mm

• Terminal Position:

  SINGLE
