The recommended crystal oscillator frequency for the LM3S2739-IQC50-A2T is 12 MHz, as specified in the datasheet. However, it's also possible to use other frequencies, such as 16 MHz or 20 MHz, with proper configuration and calibration.
The LM3S2739-IQC50-A2T has a built-in USB OTG (On-The-Go) interface. To configure it, you need to use the USB library provided by Texas Instruments, which includes APIs for device mode, host mode, and OTG mode. You'll also need to configure the USB clock, pins, and interrupts according to the datasheet and application notes.
The maximum current that can be drawn from the USB interface of the LM3S2739-IQC50-A2T is 500 mA, as specified in the datasheet. However, this value may vary depending on the specific application and power supply design.
The LM3S2739-IQC50-A2T has a built-in Ethernet MAC (Media Access Controller) interface. To use it, you need to connect an external PHY (Physical Layer) device, such as the DP83848, and configure the Ethernet clock, pins, and interrupts according to the datasheet and application notes. You'll also need to use a TCP/IP stack, such as the one provided by Texas Instruments, to manage the Ethernet communication.
The maximum operating temperature range for the LM3S2739-IQC50-A2T is -40°C to 85°C, as specified in the datasheet. However, it's recommended to operate the device within a narrower temperature range, such as 0°C to 70°C, to ensure optimal performance and reliability.
Trust Checks
This model has been verified by system checks.
System Verified
Sponsored
LM3S2739-IQC50-A2T Overview
Use the download button to access the LM3S2739-IQC50-A2T schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like LM3S2,
or try a keyword search, such as Microcontrollers
