Texas Instruments recommends a 4-layer PCB with a solid ground plane, and placing the codec near the audio connectors to minimize noise. Additionally, decoupling capacitors should be placed close to the power pins, and analog and digital grounds should be separated.
To optimize for low power consumption, use the power-down mode, reduce the clock frequency, and adjust the analog and digital supply voltages. Additionally, disable unused features and use the dynamic voltage scaling feature.
The LM4549BVHX/NOPB has a thermal pad that must be connected to a thermal plane on the PCB. Ensure good thermal conductivity by using a thermal interface material and a heat sink if necessary. Also, ensure good airflow around the device.
Use an oscilloscope to measure the audio signals, and check for proper termination, impedance matching, and signal levels. Also, verify that the codec is properly configured and that the analog and digital grounds are separated.
Yes, the LM4549BVHX/NOPB is designed to meet regulatory standards such as FCC Part 15 and CE Marking. However, the final product must still undergo testing and certification to ensure compliance.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
LM4549BVHX/NOPB Overview
Use the download button to access the LM4549BVHX/NOPB schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like LM454,
or try a keyword search, such as Other Consumer ICs
