LM4855ITL - Texas Instruments

LM4855ITL Details

• Manufacturer Part Number:

  LM4855ITL

• Pbfree Code:

  No

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  BGA

• Package Description:

  MICRO SMD-18

• Pin Count:

  18

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Manufacturer:

  Texas Instruments

• YTEOL:

  0

• Bandwidth-Nom:

  20 kHz

• Consumer IC Type:

  AUDIO AMPLIFIER

• JESD-30 Code:

  R-PBGA-B18

• JESD-609 Code:

  e0

• Length:

  2.225 mm

• Moisture Sensitivity Level:

  1

• Number of Channels:

  3

• Number of Functions:

  1

• Number of Terminals:

  18

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Power-Nom:

  1.1 W

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  IBGA

• Package Equivalence Code:

  BGA18,4X5,20/17

• Package Shape:

  RECTANGULAR

• Package Style:

  GRID ARRAY, INTERSTITIAL PITCH

• Qualification Status:

  Not Qualified

• Supply Voltage-Max (Vsup):

  5 V

• Supply Voltage-Min (Vsup):

  2.6 V

• Surface Mount:

  YES

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  BALL

• Terminal Pitch:

  0.866 mm

• Terminal Position:

  BOTTOM

• Width:

  1.996 mm
