Texas Instruments provides a recommended PCB layout in the LM5064 datasheet, which includes a thermal pad connected to a copper plane on the PCB to dissipate heat. Additionally, it's recommended to use a 2-ounce copper PCB and to keep the thermal pad away from other components to minimize thermal resistance.
The input capacitor selection depends on the input voltage, ripple current, and ESR requirements. A general rule of thumb is to choose a capacitor with a voltage rating at least 1.5 times the maximum input voltage, and an ESR that meets the recommended maximum ESR value in the datasheet. X7R or X5R ceramic capacitors are recommended for their low ESR and high reliability.
The maximum output current of the LM5064 is dependent on the input voltage, output voltage, and thermal conditions. The datasheet provides a graph of output current vs. input voltage, and it's recommended to derate the output current based on the ambient temperature and thermal resistance of the package. As a general rule, the maximum output current should not exceed 4A.
To ensure stability, it's recommended to follow the datasheet's guidelines for output capacitor selection, including the recommended value and ESR range. Additionally, the input capacitor should be placed close to the VIN pin, and the output capacitor should be placed close to the VOUT pin. It's also recommended to add a small ceramic capacitor (e.g., 10nF) between the VOUT pin and GND to improve stability.
The EN (enable) pin is used to turn the LM5064 on and off. When the EN pin is pulled high (above 1.4V), the device is enabled, and when it's pulled low (below 0.4V), the device is disabled. The EN pin can be connected to a logic signal or a switch to control the power-on and power-off sequence of the device.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
LM5064PMH/NOPB Overview
Use the download button to access the LM5064PMH/NOPB schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like LM506,
or try a keyword search, such as Power Management Circuits
