LM56CIMM - Texas Instruments

LM56CIMM Details

• Manufacturer Part Number:

  LM56CIMM

• Pbfree Code:

  No

• Part Life Cycle Code:

  Obsolete

• Package Description:

  PLASTIC, MO-187, SOP-8

• Manufacturer:

  Texas Instruments

• YTEOL:

  0

• Accuracy-Max (Cel):

  4 Cel

• Body Breadth:

  3 mm

• Body Height:

  0.965 mm

• Body Length or Diameter:

  3 mm

• Housing:

  PLASTIC

• JESD-609 Code:

  e0

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  8

• Operating Current-Max:

  0.23 mA

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  TSSOP8,.19

• Package Shape/Style:

  SQUARE

• Sensors/Transducers Type:

  TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,DUAL TRIP POINT

• Supply Voltage-Max:

  10 V

• Supply Voltage-Min:

  2.7 V

• Surface Mount:

  YES

• Terminal Finish:

  TIN LEAD

• Termination Type:

  SOLDER
