LM97593VH - Texas Instruments

LM97593VH Details

• Manufacturer Part Number:

  LM97593VH

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  QFP

• Package Description:

  PLASTIC, QFP-128

• Pin Count:

  128

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Texas Instruments

• YTEOL:

  0

• Consumer IC Type:

  CONSUMER CIRCUIT

• JESD-30 Code:

  R-PQFP-G128

• JESD-609 Code:

  e0

• Length:

  20 mm

• Moisture Sensitivity Level:

  3

• Number of Functions:

  1

• Number of Terminals:

  128

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  FQFP

• Package Equivalence Code:

  QFP128,.67X.93,20

• Package Shape:

  RECTANGULAR

• Package Style:

  FLATPACK, FINE PITCH

• Peak Reflow Temperature (Cel):

  245

• Seated Height-Max:

  3.4 mm

• Supply Voltage-Max (Vsup):

  3.6 V

• Supply Voltage-Min (Vsup):

  3 V

• Surface Mount:

  YES

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  14 mm
