LMG1210RVRT - Texas Instruments

LMG1210RVRT Details

• Manufacturer Part Number:

  LMG1210RVRT

• Brand Name:

  Texas Instruments

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.90

• Date Of Intro:

  2018-02-18

• Manufacturer:

  Texas Instruments

• YTEOL:

  15

• Additional Feature:

  TPHL AND TPLH CONSIDERED FOR INDEPENDENT INPUT MODE

• Built-in Protections:

  THERMAL; UNDER VOLTAGE

• Interface IC Type:

  HALF BRIDGE BASED PERIPHERAL DRIVER

• JESD-30 Code:

  R-PBCC-B19

• JESD-609 Code:

  e3

• Length:

  4 mm

• Moisture Sensitivity Level:

  2

• Number of Channels:

  2

• Number of Functions:

  1

• Number of Terminals:

  19

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Current Flow Direction:

  SOURCE AND SINK

• Output Current-Max:

  3 A

• Output Peak Current Limit-Nom:

  0.11 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HVBCC

• Package Shape:

  RECTANGULAR

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Peak Reflow Temperature (Cel):

  260

• Seated Height-Max:

  0.8 mm

• Supply Voltage-Max:

  6 V

• Supply Voltage-Min:

  6 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Temperature Grade:

  AUTOMOTIVE

• Terminal Finish:

  Tin (Sn)

• Terminal Form:

  BUTT

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  30

• Turn-off Time:

  0.018 µs

• Turn-on Time:

  0.018 µs

• Width:

  3 mm
