LP2967IBP-2833 - Texas Instruments

LP2967IBP-2833 Details

• Manufacturer Part Number:

  LP2967IBP-2833

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  BGA

• Package Description:

  BGA-8

• Pin Count:

  8

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Texas Instruments

• YTEOL:

  0

• Dropout Voltage1-Max:

  0.425 V

• Dropout Voltage1-Nom:

  0.24 V

• Dropout Voltage2-Max:

  0.425 V

• Input Voltage-Max:

  16 V

• Input Voltage-Min:

  3.8 V

• JESD-30 Code:

  R-PBGA-B8

• Length:

  1.946 mm

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  8

• Operating Temperature TJ-Max:

  125 °C

• Operating Temperature TJ-Min:

  -40 °C

• Output Current1-Max:

  0.15 A

• Output Current2-Max:

  0.15 A

• Output Voltage1-Max:

  2.884 V

• Output Voltage1-Min:

  2.716 V

• Output Voltage1-Nom:

  2.8 V

• Output Voltage2-Max:

  3.399 V

• Output Voltage2-Min:

  3.201 V

• Output Voltage2-Nom:

  3.3 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  VFBGA

• Package Shape:

  RECTANGULAR

• Package Style:

  GRID ARRAY, VERY THIN PROFILE, FINE PITCH

• Regulator Type:

  FIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR

• Seated Height-Max:

  0.85 mm

• Surface Mount:

  YES

• Terminal Form:

  BALL

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  BOTTOM

• Voltage Tolerance-Max:

  3%

• Width:

  1.412 mm
