Description:The M1016204 series is a 16Mbit high performance non-volatile MRAM with speed up to 108MHz. The M1016204 offers superior reliability and greater than 20-year data retention (at 85°C). It does not require backup battery or capacitor(s) compared to non-volatile SRAM. The M1016204 supports Quad SPI, SDR and DDR interface. It operates at 1.8V typical from -40°C to +105°C (industrial plus version) and offered in an SOIC or DFN (WSON) package.
Renesas provides a recommended PCB layout guide in their application note (APN) documents, which can be found on their website. The guide includes thermal vias, heat sink recommendations, and PCB layer stack-up suggestions to ensure optimal thermal performance.
Renesas recommends following the power sequencing guidelines outlined in the datasheet, which involves powering up the device in a specific order to prevent damage or malfunction. Additionally, Renesas provides power sequencing diagrams and application notes that can be used as a reference.
Renesas recommends using high-quality, low-ESR decoupling capacitors with a value of 0.1uF to 1uF, placed as close as possible to the power pins. The datasheet provides more detailed information on decoupling capacitor selection and placement.
Renesas provides a troubleshooting guide in their application notes, which covers common issues and their solutions. Additionally, engineers can use Renesas' online support resources, such as FAQs, knowledge base articles, and community forums, to find answers to common problems.
The recommended operating temperature range for the M10162040108X0PWAY is -40°C to 125°C, as specified in the datasheet. However, it's essential to note that the device's performance and reliability may be affected at extreme temperatures, and additional thermal management may be required.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
M10162040108X0PWAY Overview
Use the download button to access the M10162040108X0PWAY schematic symbol, PCB footprint, and 3D model.
