MAT14ARZ - Analog Devices

MAT14ARZ Details

• Manufacturer Part Number:

  MAT14ARZ

• Brand Name:

  Analog Devices Inc

• Pbfree Code:

  No

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  SOIC

• Package Description:

  ROHS COMPLIANT, SOIC_N-14

• Pin Count:

  14

• Manufacturer Package Code:

  R-14

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8541.21.00.95

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  10

• Additional Feature:

  LOW NOISE

• Collector Current-Max (IC):

  0.03 A

• Collector-Emitter Voltage-Max:

  40 V

• Configuration:

  COMPLEX

• DC Current Gain-Min (hFE):

  200

• JEDEC-95 Code:

  MS-012AB

• JESD-30 Code:

  R-PDSO-G14

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Number of Elements:

  4

• Number of Terminals:

  14

• Operating Temperature-Max:

  150 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  NPN

• Qualification Status:

  Not Qualified

• Surface Mount:

  YES

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30

• Transistor Application:

  AMPLIFIER

• Transistor Element Material:

  SILICON

• Transition Frequency-Nom (fT):

  300 MHz
