MAX20094ATIA/VY+ - Analog Devices

Description: Charger IC Lithium Ion 28-TQFN (5x5)

Download MAX20094ATIA/VY+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
MAX20094ATIA/VY+ - Analog Devices - PCB symbol
click to zoom
PCB Footprints
MAX20094ATIA/VY+ - Analog Devices PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - 28-TQFN (5x5)_2024
click to zoom
3D Models
MAX20094ATIA/VY+ - Analog Devices - 3D model - Quad Flat No-Lead - 28-TQFN (5x5)_2024
click to zoom

MAX20094ATIA/VY+ Details

  • Manufacturer Part Number:

    MAX20094ATIA/VY+

  • Brand Name:

    Analog Devices Inc

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    28-LFCSP_SS-5X5X0.75

  • Package Description:

    TQFN-EP-28

  • Pin Count:

    28

  • Manufacturer Package Code:

    28-LFCSP_SS-5X5X0.75

  • Country Of Origin:

    Japan, Mainland China, Malaysia, Philippines, Singapore, South Korea, Taiwan, Thailand, USA

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Date Of Intro:

    2018-02-12

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    9

  • Adjustable Threshold:

    YES

  • Analog IC - Other Type:

    LINEAR BATTERY CHARGER

  • JESD-30 Code:

    S-XQCC-N28

  • JESD-609 Code:

    e3

  • Length:

    5 mm

  • Moisture Sensitivity Level:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    28

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    UNSPECIFIED

  • Package Code:

    HVQCCN

  • Package Equivalence Code:

    LCC28,.2SQ,20

  • Package Shape:

    SQUARE

  • Package Style:

    CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

  • Peak Reflow Temperature (Cel):

    260

  • Screening Level:

    AEC-Q100

  • Seated Height-Max:

    0.8 mm

  • Supply Current-Max (Isup):

    0.055 mA

  • Supply Voltage-Max (Vsup):

    36 V

  • Supply Voltage-Min (Vsup):

    4.5 V

  • Supply Voltage-Nom (Vsup):

    14 V

  • Surface Mount:

    YES

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Finish:

    Matte Tin (Sn) - annealed

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    QUAD

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    5 mm

MAX20094ATIA/VY+ Frequently Asked Questions (FAQs)

  • A good PCB layout for the MAX20094ATIA/VY+ involves keeping the input and output traces short and away from each other, using a solid ground plane, and placing decoupling capacitors close to the device. A 4-layer PCB with a dedicated power plane and a dedicated ground plane is recommended. Additionally, it's essential to follow the layout guidelines provided in the datasheet and application notes.
  • The selection of input and output capacitors for the MAX20094ATIA/VY+ depends on the specific application requirements. In general, X7R or X5R ceramic capacitors with a voltage rating of 10V or higher are recommended. The capacitance value should be chosen based on the desired cutoff frequency and the impedance of the input and output stages. A good starting point is to use 1uF to 10uF capacitors for the input and output stages.
  • The MAX20094ATIA/VY+ has an operating temperature range of -40°C to +125°C. However, the device's performance may degrade at extreme temperatures, and the output voltage may vary. It's essential to ensure that the device is operated within the recommended temperature range for optimal performance and reliability.
  • To troubleshoot issues with the MAX20094ATIA/VY+, start by checking the input voltage, output voltage, and current consumption. Verify that the device is properly powered and that the input and output capacitors are correctly connected. Check for any signs of overheating, such as excessive temperature or thermal shutdown. Use an oscilloscope to monitor the input and output waveforms and look for any signs of oscillation or instability. Consult the datasheet and application notes for troubleshooting guidelines and FAQs.
  • Yes, the MAX20094ATIA/VY+ is suitable for high-reliability and automotive applications. The device is AEC-Q100 qualified and meets the requirements for automotive applications. However, it's essential to follow the recommended design and layout guidelines, and to ensure that the device is operated within the recommended temperature range and voltage limits. Additionally, it's recommended to perform thorough testing and validation to ensure that the device meets the specific requirements of the application.
