MAX9263GCB/V+T footprint, schematic symbol and 3D model by Analog Devices

Symbol

click to zoom

PCB Footprints

MAX9263GCB/V+T - Analog Devices PCB footprint - Quad Flat Packages - Quad Flat Packages - 64-TQFP_EP-10X10X1.0-3

click to zoom

3D Models

MAX9263GCB/V+T - Analog Devices - 3D model - Quad Flat Packages - 64-TQFP_EP-10X10X1.0-3

click to zoom

Datasheet Download Datasheet
Stock & Prices Price & Stock for MAX9263GCB/V+T
Part Number MAX9263GCB/V+T
Manufacturer Analog Devices
Pin Count 65
Part Category Integrated Circuit
Package Category Quad Flat Packages
Footprint Name Quad Flat Packages - 64-TQFP_EP-10X10X1.0-3
Released Date Nov 4, 2020
Last Modified Date Aug 13, 2025 11:36 AM UTC
Pinout / Pin List Click Here (Member Only)

MAX9263GCB/V+T Details

Manufacturer Part Number:
MAX9263GCB/V+T
Brand Name:
Analog Devices Inc
Rohs Code:
Yes
Part Life Cycle Code:
End Of Life
Part Package Code:
64-TQFP_EP-10X10X1.0
Package Description:
TQFP-64
Pin Count:
64
Manufacturer Package Code:
64-TQFP_EP-10X10X1.0
Country Of Origin:
Japan, Mainland China, Malaysia, Philippines, Singapore, South Korea, Taiwan, Thailand, USA
ECCN Code:
EAR99
HTS Code:
8542.39.00.60
Date Of Intro:
2011-01-18
Manufacturer:
Analog Devices Inc
YTEOL:
1
Additional Feature:
ESD Value for OUT+, OUT- pins is 3B
Differential Output:
YES
Driver Number of Bits:
1
High Level Input Current-Max:
0.00001 A
Input Characteristics:
STANDARD
Interface IC Type:
LINE DRIVER
Interface Standard:
ISO 10605
JESD-30 Code:
S-PQFP-G64
JESD-609 Code:
e3
Length:
10 mm
Moisture Sensitivity Level:
3
Number of Functions:
1
Number of Terminals:
64
Operating Temperature-Max:
105 °C
Operating Temperature-Min:
-40 °C
Out Swing-Min:
0.24 V
Output Characteristics:
DIFFERENTIAL
Output Low Current-Max:
0.002 A
Output Polarity:
COMPLEMENTARY
Package Body Material:
PLASTIC/EPOXY
Package Code:
HTFQFP
Package Equivalence Code:
TQFP64,.47SQ
Package Shape:
SQUARE
Package Style:
FLATPACK, HEAT SINK/SLUG, THIN PROFILE, FINE PITCH
Peak Reflow Temperature (Cel):
260
Seated Height-Max:
1.2 mm
Supply Current-Max:
188 mA
Supply Voltage-Max:
1.9 V
Supply Voltage-Min:
1.7 V
Supply Voltage-Nom:
1.8 V
Surface Mount:
YES
Technology:
CMOS
Temperature Grade:
INDUSTRIAL
Terminal Finish:
Matte Tin (Sn) - annealed
Terminal Form:
GULL WING
Terminal Pitch:
0.5 mm
Terminal Position:
QUAD
Time@Peak Reflow Temperature-Max (s):
30
Width:
10 mm
