- Datasheet Download Datasheet
- Stock & Prices $ Price & Stock for MC33FS6510NAE
- Part Number MC33FS6510NAE
- Manufacturer NXP
- Pin Count 49
- Part Category Integrated Circuit
- Package Category Quad Flat Packages
- Footprint Name Quad Flat Packages - 48-pin LQFP-EP
- Released Date Sep 8, 2021
- Last Modified Date Mar 7, 2023 4:10 PM UTC
- Pinout / Pin List Click Here (Member Only)
MC33FS6510NAE Details
-
Manufacturer Part Number:
MC33FS6510NAE
-
Rohs Code:
Yes
-
Part Life Cycle Code:
Active
-
Package Description:
LQFP-48
-
Country Of Origin:
Mainland China
-
HTS Code:
8542.39.00.01
-
Factory Lead Time:
16 Weeks
-
Manufacturer:
NXP Semiconductors
-
YTEOL:
10
-
JESD-30 Code:
S-PQFP-G48
-
Length:
7 mm
MC33FS6510NAE Frequently Asked Questions (FAQs)
-
A 4-layer PCB with a solid ground plane and a separate power plane is recommended. Keep the analog and digital grounds separate and connect them at a single point. Use a 10uF capacitor between VCC and GND, and a 1uF capacitor between AVCC and AGND.
-
To configure the MC33FS6510NAE for low-power mode, set the PWDN pin high and the EN pin low. This will put the device in shutdown mode, reducing power consumption to less than 1uA.
-
The MC33FS6510NAE can handle input voltages up to 18V, but it is recommended to operate within the specified range of 4.5V to 15V for optimal performance and reliability.
-
Use a logic analyzer or oscilloscope to monitor the device's pins and verify that the input signals are correct. Check the power supply voltage and ensure it is within the specified range. Also, verify that the device is properly configured and that the firmware is correct.
-
The MC33FS6510NAE is rated for operation up to 105°C, but it is recommended to operate within the specified temperature range of -40°C to 85°C for optimal performance and reliability.
Trust Checks
Community Provided
System Verified
Community Approved
MC33FS6510NAE Overview
Use the download button to access the MC33FS6510NAE schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like MC33F,
or try a keyword search, such as Network Interfaces
About NXP
NXP Semiconductors is a leading manufacturer of semiconductor devices with a wide range of semiconductor solutions, including microcontrollers, sensors, connectivity solutions, power management ICs, and security solutions. These products are used in a variety of applications such as automotive, industrial automation, smart homes, mobile devices, and more.
NXP Semiconductors is one of the world’s largest semiconductor companies and is headquartered in Eindhoven, the Netherlands.
