MOC3020X footprint, schematic symbol and 3D model by Isocom

Symbol

PCB Footprints

3D Models

MOC3020X Details

The recommended operating temperature range for the MOC3020X is -40°C to 100°C.
To ensure reliability in high-temperature applications, it is recommended to derate the device's current and voltage ratings according to the temperature derating curve provided in the datasheet.
The maximum allowable voltage across the input-to-output isolation barrier is 5000 Vrms for 1 minute, as per the UL1577 standard.
Yes, the MOC3020X can be used in high-frequency switching applications up to 1 MHz, but the user should ensure that the device is properly bypassed and decoupled to minimize electromagnetic interference (EMI).
The correct current-limiting resistor value can be calculated using the formula: R = (Vcc - Vf) / If, where Vcc is the supply voltage, Vf is the forward voltage drop of the LED, and If is the desired forward current.

Community Provided

System Verified

Community Approved

Use the download button to access the MOC3020X schematic symbol, PCB footprint, and 3D model.

To find more CAD model downloads similar to this part, try a partial part number search, like MOC30, or try a keyword search, such as Optocoupler
