MPF5020AVNA0ES - NXP

Description: NXP - MPF5020AVNA0ES - POWER MANAGEMENT IC, -40 TO 105DEG C

Download MPF5020AVNA0ES Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
MPF5020AVNA0ES - NXP PCB footprint - Other - Other -  HVQFN40 (SOT618-14)
click to zoom
3D Models
MPF5020AVNA0ES - NXP  - 3D model - Other -  HVQFN40 (SOT618-14)
click to zoom

MPF5020AVNA0ES Details

  • Manufacturer Part Number:

    MPF5020AVNA0ES

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Not Recommended

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Factory Lead Time:

    16 Weeks

  • Date Of Intro:

    2020-04-15

  • Manufacturer:

    NXP Semiconductors

  • YTEOL:

    9

  • Analog IC - Other Type:

    INTEGRATED POWER MANAGEMENT UNIT

  • Moisture Sensitivity Level:

    3

  • Peak Reflow Temperature (Cel):

    260

  • Terminal Finish:

    Tin (Sn)

  • Time@Peak Reflow Temperature-Max (s):

    40

MPF5020AVNA0ES Frequently Asked Questions (FAQs)

  • NXP provides a recommended PCB layout in the application note AN12215, which includes guidelines for component placement, routing, and thermal management to ensure optimal performance and minimize electromagnetic interference (EMI).
  • The MPF5020AVNA0ES can be configured using the I2C interface to set the output voltage and current limits. The device has a set of registers that can be programmed to set the desired output voltage and current limits. Refer to the datasheet and application notes for more information on the register settings and programming.
  • The thermal derating curve for the MPF5020AVNA0ES is not explicitly provided in the datasheet. However, NXP provides a thermal model and thermal resistance data in the datasheet, which can be used to estimate the junction temperature and derate the device accordingly. Additionally, NXP's thermal simulation tools can be used to simulate the thermal performance of the device in a specific application.
  • To ensure EMC with the MPF5020AVNA0ES, follow the guidelines provided in the application note AN12215, which includes recommendations for PCB layout, component selection, and shielding. Additionally, ensure that the device is properly decoupled and filtered, and that the system is designed to meet the relevant EMC standards and regulations.
  • The recommended input capacitor value and type for the MPF5020AVNA0ES depend on the specific application and input voltage. As a general guideline, a low-ESR ceramic capacitor with a value of 10uF to 22uF is recommended. Refer to the datasheet and application notes for more information on input capacitor selection and design considerations.
